BS Rod Seal

  • Pressure: below 400 Bar

  • Temperature: -35  to +110℃; Speed: 0.5m/s

  • Media: Hydraulic oils (mineral oil-based)

  • Material: High-grade PU

  • Hardness: 90-95 Shore A

  • Color:Jasper

1. Description

BS Rod seal of Forever Seals is for hydraulic cylinders, single-acting, polyurethane u-cup design with secondary sealing lip. For high-pressure applications. Robust seal profile for harshest operating conditions. ISO 5597, ISO 6020.


2. Installation Recommendation


3. Technical Data
Pressure: below 400 Bar,
Temperature: -35  to +110℃; Speed: 0.5m/s
Media: Hydraulic oils (mineral oil-based)
Material: High-grade PU
Hardness: 90-95 Shore A; Color:Jasper

4. Advantages
Insensibility against shock loads and pressure peaks
High resistance against extrusion
Perfect sealing performance under low pressure enven O-pressure
Easy installation
